The BASS 30K has been carefully designed with the highest technology, with high efficiency and performance for car audio systems aimed at sub-bass and bass responses, in the frequency range of 8Hz to 250Hz. It has a maximum power of 30,000 Watts in 1 channel of 1 ohm; It features customized adjustments according to the trunk size and the most prominent frequency of each vehicle, through BASS BOOST and the option to choose the central frequency. This amplifier offers much more displacement control, through its SUBSONIC FILTER, volume control and LOW PASS, to get your bass just perfect. Welcome to the audio world by Taramps!
| Operation class | Class D |
|---|---|
| Minimum Output Impedance | 1 ohm |
| Number of Channels | 01 |
| Maximum power | @ 14.4 VDC - 1 Ohm: 30000 Watts RMS @ 14.4 VDC - 2 Ohms: 17010 Watts RMS |
| Input Sensitivity | 400mV |
| Signal to Noise Ratio | >90dB |
| Frequency Response | 8Hz ~ 250Hz (-3dB) |
| Crossover high pass (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| Crossover low pass (LPF) | 60Hz ~ 250Hz (-12dB/8ª) Variable |
| bass boost | Parametric, freq.: 35 ~ 60Hz / Boost: 0 a +12dB |
| Efficiency | 90% |
| Input Impedance | 22K Ohms |
| protection system | Output Short / Short on output relative to GND / High and Low Power Supply and Thermal protection |
| Minimum Supply Voltage | 9 VDC |
| Maximum Supply Voltage | 17 VDC |
| Consumption at rest | 400mA |
| Maximum music consumption | 1156A |
| Maximum consumption in sinusoidal signal | 2312A |
| Dimensions (WxHxD) | 9.37" x 2.79" x 41.10" (238 x 71 x 1044mm) |
| Weight | 42.24lb (19,20kg) |
| EAN | 7898556844109 |
